Making a Door
Automate the production of panel equipment doors. The system edge-treads, bevels and drills efficiently, reducing the need for labor and improving production speed.
EMD DRILLING & MILLING CENTER For Composite door cabinet
Features – We aim to make your production smarter, faster and more cost-effective with minimal manual labor
- This machine is suitable for panel cabinet doors’ grooves, milling and drilling, as well as the processing of various process modules, such as integrated handles, chamfers, hinge holes, etc.
- Automatic tool changing system, tool magazine capacity 8 positions
- Thickness sensing unit that can compensate for thickness errors
- Scanner that recognizes QR codes and barcodes
- Dual zone processing, two sheets can be loaded simultaneously
Main Components
- One 6KW automatic tool changing carousel
- One 5.5KW horizontal manual tool changing carousel
- One 3.5KW 45° beveling carousel with manual tool changing
- One 3.5KW horizontal manual tool changing carousel
- One 0.75KW Lamello cutting tool motor
- One 0.6KW hole drilling carousel
- One 1.5KW hinge drill
X-, Y-, Z-axes, all using 1KW motors, high accuracy, high speed, overload protection, stable operation at low speeds and low noise level.
Automatic tool changing, 8 tool magazines, can be equipped with various milling tools, simple and fast, with different tools, it is possible to achieve different processes
Weihong control system, easy and simple to use.
Automatic tool calibration sensor, which enables accurate tool calibration
High-quality cylinder units: used for pressing panels
Bakelite table, higher hardness, not easily deformed.
High rigidity linear guides and high load capacity ensure smoother operation at high speeds and high accuracy, low noise level and long service life.
Seos (alloy) reinforced steel structure, extremely high strength and toughness, high impact resistance, high wear resistance, 100% compatibility of couplings and gears, more stable operation
Examples of door making products
EMD‑1230D
| Parameter | Value |
|---|---|
| Travel range (X/Y/Z) | 4100 × 200 × 100 mm |
| Maximum working area | 3000 × 1200 × 50 mm |
| Table size | 2800 × 550 mm |
| Table construction | Bakelite table |
| Motion system | Y-axis rack-and-pinion; X/Z-axis ball screw |
| Spindle powers | 6.0 kW + 5.5 kW + 2 × 1.5 kW + 0.75 kW + 600 W + 3.5 kW |
| Spindle speed | 18,000 rpm |
| Rapid traverse (X/Y/Z) | 80 / 20 / 20 m/min |
| Control system | Weihong |
| Operating voltage | 380 V |
| Total power | 26.5 kW |
